Table 4-1 Spring matching standard
Arm Type Arm Length (m) Number of Spring
Straight arm with light bar
L ≤ 3.7 1 × 5.2 spring
3.7 < L ≤ 4.5 1 × 6.3 spring
4.5 < L ≤ 5.0 2 × 6.3 spring
5.0 < L ≤ 5.5 1 × 5.2 spring + 2 × 6.3 spring
5.5 < L ≤ 6.0 3 × 6.3 spring
Folding arm
L ≤ 3.4 1 × 5.2 spring
3.4 < L ≤ 4 1 × 6.3 spring
●
The bottom of the 5.2 spring is wrapped with a red threaded protective cover.
●
The bottom of the 6.3 spring is wrapped with a blue threaded protective cover.
