The Barrier can be used together with a radar for access control in parking lots, and it primarily
consists of a top cover, casing, drive unit, control box, and barrier arm. The Barrier can be divided
into 2 categories depending on its arm position (right or left) when facing it.
Straight arm barrier and folding arm barriers are available.
Table 1-1 Barrier type
Type Description Remark
Straight arm barrier
●
Barrier with 3 m (9.84 ft) straight arm with an
opening/closing time of 0.9 s.
●
Barrier with 4 m (13.12 ft) straight arm with
an opening/closing time of 2 s.
●
Barrier with 5 m (16.40 ft) straight arm with
an opening/closing time of 3 s.
●
Barrier with 6 m (19.69 ft) straight arm with
an opening/closing time of 3 s.
Contact technical
support for specific
needs.
Folding arm barrier
●
For barriers with 3 m (9.84 ft) arms, each of
the two sections of the arm is 1.5 m (4.92 ft),
and has an opening/closing speed of 0.9 s.
●
For barriers with 4 m (13.12 ft) arms, the
main arm is 1.5 m (4.92 ft) and the sub arm is
2 m (6.56 ft). It has an opening/closing time
of 2 s.
1.2 Features
●
With its AC variable frequency motor, drive unit and balance spring, the Barrier has highly stable
and reliable operations. Its motor and spring can sustain up to 5 million uses.
●
The sheet metal casing makes it resistant to corrosion for up to 10 years.
●
Designed with a buffer strip on its arm for enhanced safety. The buffer strip is made of
high-molecular-weight polyurethane (PU) which remains soft and not stiff in cold environments.
It has a lifespan for more than 10 years.
●
Automatically rises when the barrier arm makes contact with an object.
●
Barriers with 3 m (9.84 ft) or 4 m (13.12 ft) straight arms support the anti-collision function. A
turning gear is installed between the arm and the main shaft, allowing the arm to swing back
from a collision to avoid mechanical damage.
●
The arm automatically rises at 90° in case of power failure. You can contact technical support to
customize the angle.
●
Anti-drop function activates through its connection with the radar, loop, or IR sensor.
●
12 VDC power adapter that is capable of supplying power to the connected radar.
