User's Manual
99
Channel type
Configure the channels.
Analog Channel: Select the transmission medium such as CVI, CVBS, and then follow the
onscreen instructions to complete the settings.
IP Channel: Select a channel for IP camera from the last channel number, for example, in
Figure 5-65, select from the
17–24 check box. Then follow the onscreen instructions to
complete the settings.
The 17–24 channels are only for IP camera and the range changes dependent on the
model you purchased.
The channel selection for analog camera or IP camera are in sequence, for example, if
you want to select channels for IP camera, you need to select the 17–24 check box first,
and then you cannot jump to select the channel 15 directly until you have selected the
channel 16.
Click Apply and follow the onscreen instructions to complete the settings.
5.5.7 Upgrading Coaxial Camera
Select Main Menu > CAMERA > COAXIAL UPGRADE.
