Dahua HD IR Bullet Network Camera Quick Start Guide
7
Port name
SN
Connector name
Function description
I/O Port
1
ALARM_IN1
Alarm input port, receive on-off signal from external
alarm source.
2
ALARM_OUT1
Alarm output port, output alarm signal to alarm
device.
3
ALARM_GND
Ground terminal.
Table 1-2
1.2 Dimension
Note
The following figure is for reference only, which is only used to know the device
dimension.
Refer to 错误!未找到引用源。 for the dimension of the device. The unit is mm (inch).
Figure 1-2
