User’s Manual
88
Sub screen
Configure the settings for the tour parameters for both Main Screen and Sub Screen.
Tour parameters
Parameter Description
Enable Enable tour function.
Interval (Sec.)
Enter the amount of time that you want each channel group displays on the
screen. The value ranges from 5 seconds to 120 seconds, and the default
value is 5 seconds.
Motion Tour, Alarm
Tour
Select the View 1 or View 8 for Motion Tour and Alarm Tour (system alarm
events).
Live Layout
In the Live Layout list, select View 1, View 4, View 8, or other modes that are
supported by the Device.
Channel Group
Display all channel groups under the current Window Split setting.
Add a channel group: Click Add, in the pop-up Add Group channel,
select the channels to form a group, and then click Save.
Delete a channel group: Select the checkbox of any channel group, and
then click Delete.
Edit a channel group: Select the checkbox of any channel group and
then click Modify, or double-click on the group. The Modify Channel
Group dialog box is displayed. You can regroup the channels.
Click Move up or Move down to adjust the position of channel group.
Click Apply to save the settings.
