3
Dimensions and components of model Y (mm [inch])
Table 1-2 Component description (2)
No.
Name
No.
Name
1
Temperature monitoring unit
5
Display
2
IR light
6
Card swiping area
3
Phototransistor
7
White LED illuminator
4
Dual cameras
8
Mic
