Dahua DHI-ASI7213X-V1-T1 User Manual

5
Port
Cable Color
Cable Name
Description
Blue
CASE
Tamper alarm input of the external card reader.
White
D1
Wiegand D1 input (connected to external card
reader)/output (connected to controller).
Green
D0
Wiegand D0 input (connected to external card
reader)/output (connected to controller).
Brown
LED
Connected to external reader and verify card
number.
Yellow
B
RS-485 negative electrode input (connected to
external card reader)/output (connected to
controller, or connected to door control security
module).
 If the security module is enabled, you need to
purchase access control security module
separately. The security module needs
separate power supply to provide power.
 Once the security module is enabled, the exit
button, lock control and firefighting linkage will
be invalid.
Purple
A
RS-485 positive electrode input (connected to
external card reader)/output (connected to
controller, or connected to door control security
module).
 If the security module is enabled, you need to
purchase access control security module
separately. The security module needs
separate power supply to provide power.
 Once the security module is enabled, the exit
button, lock control and firefighting linkage will
be invalid.
CON2
White and
red
ALARM1_N
O
Alarm 1 normally open output port.
White and
orange
ALARM1_C
OM
Alarm 1 common output port.
White and
blue
ALARM2_N
O
Alarm 2 normally open output port.
White and
gray
ALARM2_C
OM
Alarm 2 common output port.
White and
green
GND
Connected to the common GND port.
White Brown
ALARM1
Alarm 1 input port.
White and
yellow
GND
Connected to the common GND port.
White and
ALARM2
Alarm 2 input port.
