Procedure
Step 1 Select Main Menu > STORAGE > Disk Group.
Figure 5-209 Disk group
Step 2 (Optional) If Disk Quota is selected is shown on the page, click Switch to Disk Group
Mode and then follow the on-screen instructions to format disks.
Step 3 Select the group for each HDD, and then click Apply.
After configuring HDD group, under the Main Stream tab, Sub Stream tab and
Snapshot tab, configure settings to save the main stream, sub stream and snapshot
to different disk groups.
5.12.5 Disk Quota
You can allocate a certain storage capacity for each channel to manage the storage space
properly.
Background Information
●
If Disk group mode selected. is shown in the interface, click Switch to Quota Mode.
●
Disk quota mode and disk group mode can not be selected at the same time.
Procedure
Step 1 Select Main Menu > STORAGE > Disk Quota.
