Dahua N84B3P

User's Manual
299
Figure 5-259 Display
Step 2 Configure the parameters.
Table 5-78 Display parameters
Parameter
Description
Main Screen/Sub
Screen
Configure the output port format of both screens.
●
When sub screen is disabled, the format of main screen is
HDMI/VGA simultaneous output.
●
When sub screen is enabled, the format of main screen and sub
screen are non-simultaneous outputs.
◇
When output port of sub screen is set to HDMI, the output
port of main screen is set to VGA by the device.
◇
When output port of sub screen is set to VGA, the output
port of main screen is set to HDMI by the device.
Enable Decoding
After it is enabled, the device can normally decode.
Time
Title/Channel Title
Select the checkbox and the date and time of the system will be
displayed in the preview screen.
Transparency
Set the transparency of the local menu of the NVR device. The
higher the transparency, the more transparent the local menu.
Time
Title/Channel Title
Select the checkbox and the date and time of the system will be
displayed in the preview screen.
Enhancement
Select the checkbox to optimize the preview image edges.
SMD Preview
Select the checkbox to display the SMD previews in the live view
interface.
