Quick Configuration 9
Settings Figure 3-2
Table 3-2 Settings description
Add, modify and delete devices; view input channel, and modify input
channel number.
Set network, Bluetooth, serial port, date, time, hardware and MAC.
Add, delete and modify role information and account information.
View program version and upgrade.
Click at the upper right corner, and a navigation bar appears in the page. With navigation
bar, quickly return to preview, device, settings, playback, extension and homepage interfaces.
Network Settings 3.5
It includes wired network and Wi-Fi settings.
3.5.1 Wired Network
Configure IP address and DNS server of network keyboard to connect other devices in the
networking.
Before setting network parameters, ensure that the network keyboard is connected to network
correctly.
On the Settings interface, click General. Step 1
The Network interface is displayed. See Figure 3-3.
