System Configurations 53
PTZ control Figure 4-47
Table 4-8 PTZ control parameter description
Parameter
Description
Step type
It consists of fixed step and variable step.
By selecting Fixed, the step remains unchanged when PTZ turns; it
is always the set step value.
By selecting Variable, the step changes with the tilt of joystick. The
larger tilt angle represents quicker turning speed.
8 direction keys
Control turning direction of SD lens.
Zoom
Set the zoom increase/decrease of PTZ lens.
Focus
Set the focus increase/decrease of PTZ lens.
Iris
Set the iris increase/decrease of PTZ lens.
Call
Call the preset point, scan, tour and pattern.
Settings
PTZ operation settings, including the preset point, scan, tour and pattern.
SD menu
Open and close SD menu.
AUX Fn
Lighting and wiper function.
Exit
Exit PTZ control.
Use the joystick to control 8 directions of PTZ.
4.5.1 Call
Click Call. The Call interface is displayed. See Figure 4-48.
