Dahua Villa VTO

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 17
VTO2000A/VTO2000A-2 with mounting box (1)
Connect the ports on the rear panel to those in the wall through the mounting box. See
"2.3.2 Rear Panel."
Fix the VTO in the mounting box with the M3×8 screws. See Figure 3-7.
VTO2000A/VTO2000A-2 with mounting box (2)
