16
VTH Config Figure 2-15
Be used as a master VTH.
Enter “Room No.” (such as 9901 or 101#0) and press “OK” to save.
“Room no.” shall be the same with “VTH Short No.”, which is set when adding
VTH at WEB interface. Otherwise, it will fail to connect VTO.
In case of extension VTH, room no. shall end with #0. Otherwise, it will fail to
connect VTO.
Be used as an extension VTH.
1) Press [Master] and switch to “Extension”.
2) Enter “Room No.” (such as 101#1) and “Master IP” (IP address of master VTH).
“Master Name” and “Master Pwd” are the user name and password of master VTH.
Default user name is admin, and the password is the one set during device
initialization.
3) Press [OK] to save settings.
Press [SIP Server]. Step 6
The system displays “SIP Server” interface, as shown in Figure 2-16.
