7
VTNS1060A
When installing a VDP system in an apartment/business setting, several modules are available. Each module has an IN and OUT
connection, this links the various modules together. Regardless of which modules are to be used, the camera unit is always the master
and is the rst device in the chain.
VTO2000A-C
VTO2000A-B
VTO2000A-K
Link Wire
Link Wire
24v PoE
Apartment 1
24v PoE
Apartment 2
24v PoE
Apartment 3
24v PoE
VTO Module Conguration
With a PC or Laptop connected to the network switch, run the Dahua cong tool to nd the VTO unit. By default the VTO
has an IP address of 192.168.1.110, this can be changed if required via the cong tool or within the VTO web browser.
Login to the VTO via the computers web browser. Username: admin Password: admin
Select the Local Cong tab and change Device Type to Modularize Villa click Ok to save the setting.
Select the Logout option on the left menu and click Reboot Device, this will restart the VTO.
Modular System Configuration
