Dahua VTO2101E-P User Manual

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 14
Installing VTO
3.2.1 VTO6210B/VTO6210BW
VTO6210B/VTO6210BW installation
Table 3-1 Item list
No.
Item
No.
Item
1
VTO
2
Mounting bracket
3
M4 screw
4
ST3.0 screw
Fix the mounting bracket on the wall with the M4 screws, and then strengthen it with the
ST3.0 screws.
Connect the ports on the rear panel to those in the wall through the mounting bracket.
See "2.1.2 Rear Panel."
Put the VTO on the mounting bracket; fit the upper edge first and then push the lower
edge gently.
Fix the VTO on the mounting bracket with the M3 screws.
3.2.2 VTO6000CM/VTO6100C
Try not to install VTO6100C onto iron doors directly. Otherwise, signal and access card reader
performance might be compromised.

Dahua VTO2101E-P Specifications

General

Brand	Dahua
Model	VTO2101E-P
Category	Intercom System
Language	English
