Daiichi Electronics WTT2-92A-12 - Structure and Environmental Conditions; Technical Standards

Q-222-036
11
7.6 Structure and environmental conditions
Item Specification
Material BOX：ABS(V-0), Terminal board：ABS(V-0), Terminal cover：Polycarbonate
Color Munsell N1.5 (Black)
External dimensions 56×120×130mm (W×H×D)
Mass Approx. 400g
Protection rating IP30
Operating temperature and
humidity limits
-10 to 55℃ , 5 to 90% RH (Non condensing)
Storage temperature limits -40 to 70℃
Product warranty period One year period
7.7 Technical standards
Item Specification
Transducer
JIS C 1111：2019
IEC 60688 ：2012
CE marking
EMC Directive 2014/30/EU
EN 61000-6-2, EN 61000-4-2, -3, -4, -5, -6, -8, -11
EN 61000-6-4, EN 55011 classA, Group1
Low Voltage Directive 2014/35/EU
EN 61010-1
RoHS Directive 2011/65/EU+(EU)2015/863
EN IEC 63000
Safety
IEC 61010-1
Measurement Category Ⅲ, Maximum use voltage：300V, Pollution degree 2
