10. Type composition
Single Phase Active Power Transducer
Type Specification code
WTT2-92A-12-
①②③④⑤⑥
1) Rated current, 1A
① Model ② Input
③ Rated
voltage
④ Rated
current
⑤ Output (Output load range) ⑥ Auxiliary supply
B Model B 1 0 to 100W 1 AC100V 1 AC1A 2 DC0 to 1V (200Ω or more) AC80 to 264V
A -100 to 100W 2 AC105V 3 DC0 to 5V (600Ω or more) F DC80 to 264V
3 AC110V 4 DC0 to 10V (2kΩ or more) AC/DC power supply
4 AC115V 5 DC1 to 5V (600Ω or more) 3 DC20 to 57V
1 0 to 100W 5 AC200V 6 DC-5 to 5V (600Ω or more) Z Other
2 0 to 150W 6 AC210V 7 DC-10 to 10V (2kΩ or more)
3 0 to 166.7W 7 AC220V A DC0 to 1mA (10kΩ or less)
4 0 to 200W B DC0 to 5mA (2kΩ or less)
A -100 to 100W C DC0 to 10mA (1kΩ or less)
B -150 to 150W F DC4 to 20mA (550Ω or less)
C -166.7 to 166.7W G DC-1 to 1mA (10kΩ or less)
D -200 to 200W Z Other
Z Other Z Other Z Other
2) Rated current, 5A
① Model ② Input
③ Rated
voltage
④ Rated
current
⑤ Output (Output load range) ⑥ Auxiliary supply
B Model B 1 0 to 500W 1 AC100V 2 AC5A 2 DC0 to 1V (200Ω or more) AC80 to 264V
A -500 to 500W 2 AC105V 3 DC0 to 5V (600Ω or more) F DC80 to 264V
3 AC110V 4 DC0 to 10V (2kΩ or more) AC/DC power supply
4 AC115V 5 DC1 to 5V (600Ω or more) 3 DC20 to 57V
1 0 to 500W 5 AC200V 6 DC-5 to 5V (600Ω or more) Z Other
2 0 to 750W 6 AC210V 7 DC-10 to 10V (2kΩ or more)
3 0 to 833.3W 7 AC220V A DC0 to 1mA (10kΩ or less)
4 0 to 1kW B DC0 to 5mA (2kΩ or less)
A -500 to 500W C DC0 to 10mA (1kΩ or less)
B -750 to 750W F DC4 to 20mA (550Ω or less)
C -833.3 to 833.3W G DC-1 to 1mA (10kΩ or less)
D -1 to 1kW Z Other
Z Other Z Other Z Other
