Q-222-036
15
Three Phase Three Wire Active Power Transducer
Type Specification code
WTT2-92A-33-
①②③④⑤⑥
1) Rated current, 1A
① Model ② Input
③ Rated
voltage
④ Rated
current
⑤ Output (Output load range) ⑥ Auxiliary supply
B Model B 1 0 to 100W 1 AC100V 1 AC1A 2 DC0 to 1V (200Ω or more) AC80 to 264V
2 0 to 150W 2 AC105V 3 DC0 to 5V (600Ω or more) F DC80 to 264V
3 0 to 166.7W 3 AC110V 4 DC0 to 10V (2kΩ or more) AC/DC power supply
4 0 to 200W 4 AC115V 5 DC1 to 5V (600Ω or more) 3 DC20 to 57V
A -100 to 100W 6 DC-5 to 5V (600Ω or more) Z Other
B -150 to 150W 7 DC-10 to 10V (2kΩ or more)
C -166.7 to 166.7W A DC0 to 1mA (10kΩ or less)
D -200 to 200W B DC0 to 5mA (2kΩ or less)
4 0 to 200W 5 AC200V C DC0 to 10mA (1kΩ or less)
5 0 to 300W 6 AC210V F DC4 to 20mA (550Ω or less)
6 0 to 333.3W 7 AC220V G DC-1 to 1mA (10kΩ or less)
7 0 to 400W Z Other
D -200 to 200W
E -300 to 300W
F -333.3 to 333.3W
G -400 to 400W
Z Other Z Other Z Other
2) Rated current, 5A
① Model ② Input
③ Rated
voltage
④ Rated
current
⑤ Output (Output load range) ⑥ Auxiliary supply
B Model B 1 0 to 500W 1 AC100V 2 AC5A 2 DC0 to 1V (200Ω or more) AC80 to 264V
2 0 to 750W 2 AC105V 3 DC0 to 5V (600Ω or more) F DC80 to 264V
3 0 to 833.3W 3 AC110V 4 DC0 to 10V (2kΩ or more) AC/DC power supply
4 0 to 1kW 4 AC115V 5 DC1 to 5V (600Ω or more) 3 DC20 to 57V
A -500 to 500W 6 DC-5 to 5V (600Ω or more) Z Other
B -750 to 750W 7 DC-10 to 10V (2kΩ or more)
C -833.3 to 833.3W A DC0 to 1mA (10kΩ or less)
D -1 to 1kW B DC0 to 5mA (2kΩ or less)
4 0 to 1kW 5 AC200V C DC0 to 10mA (1kΩ or less)
5 0 to 1.5kW 6 AC210V F DC4 to 20mA (550Ω or less)
6 0 to 1.667kW 7 AC220V G DC-1 to 1mA (10kΩ or less)
7 0 to 2kW Z Other
D -1 to 1kW
E -1.5 to 1.5kW
F -1.667 to 1.667kW
G -2 to 2kW
Z Other Z Other Z Other
To Next Page
