OMM 1130 67
WaterCooled=ON
SET ALARM LIMITS (5)
Cond Freeze= XX.X °F
CondFlowProof= XX sec
TGZ in Heat Mode
SET ALARM LIMITS (6)
LowSourceTmp = XX.XF
LowSourceDif = XX.XF
Set Air-Cooled Condenser Fans
Water-cooled = Off
SET FANS SPs (1)
Fan Stages=X
Speedtrol=Yes/No
Water-cooled = Off
SET FANS SPs (2)
Stage ON Deadband (F)
Stg2 Stg3 Stg4
XXX XXX XXX
Water-cooled = Off
SET FANS SPs (3)
Stage Off Deadband (F)
Stg2 Stg3 Stg4
XXX XXX XXX
The SET FANS SP screens 2 through 5 establish the temperature that will stage the condenser fans on and
off. These screens apply only to units set up for use with air-cooled condensers (WaterCooled=No). On
such units, the settings do not have to be entered if the unit controller is not used to stage condenser fans
for head pressure control. If the MicroTech II unit controller is not used to control the fans, some other
method must be used.
Water cooled=Off
SET FANS SPs (4)
Cond Sat Temp Target
Set Point= XXX.X °F
Water cooled=Off
SET FANS SPs (5)
# Fans On At Startup
>75°F >90°F >105°F
X X X
To Next Page
