6 WGZ030D through WGZ200D OMM 1130
Components
Figure 3, Compressor Locations
423
1
Circuit 2 Circuit 1
Control Panel
Evaporator
Evaporator and
Condenser
Connections
NOTE: Models WGZ150 to WGZ200 add a #5 compressor to circuit #1 and a #6 compressor to
circuit #2.
