Si121175
Removal Procedure 1
Table of Contents
1. Removal of Outer Panels ........................................................................2
2. Removal of Electrical Box (Pattern 1) .....................................................3
3. Removal of Electrical Box (Pattern 2) .....................................................7
4. Removal of PCBs (Pattern 1)................................................................12
5. Removal of PCBs (Pattern 2)................................................................16
6. Removal of Fan Motor...........................................................................19
7. Removal of Sound Blankets..................................................................20
8. Removal of Coils / Thermistors .............................................................22
9. Removal of Four Way Valve / Defrost Solenoid Valve..........................24
10.Removal of Distributor...........................................................................26
11.Removal of Compressor .......................................................................27
Note:
The illustrations may be slightly different depending on the model.
The illustrations are for heat pump models as representative.
