IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS 30 www.DaikinApplied.com
IsolaTor InformaTIon
Table 8: Isolator Information - Microchannel Units
AGZ-E
Model
Rubber-In-Shear (RIS) Mounts Spring Isolator Mountings
M1 M2 M3 M4 M5 M6 M7 M8 M1 M2 M3 M4 M5 M6 M7 M8
030
Brown Brown Brown Brown Dark Grn Dk Prple Black Black
035
Brown Brown Brown Brown Dark Grn Dk Prple Black Black
040
Brown Brown Brown Brown Dark Grn Dk Prple Black Black
045
Brown Brown Brown Brown Dark Grn Dk Prple Dk Prple Black
050
Brown Brown Brown Brown Dark Grn Dk Prple Dk Prple Black
055
Brown Brown Brown Brown Dark Grn Dk Prple Dk Prple Black
060
Brown Brown Brown Brown Dark Grn Dk Prple Dk Prple Black
065
Brown Brown Brown Brown Dark Grn Dk Prple Dk Prple Black
070
Brown Brown Brown Brown Dark Grn Dk Prple Dk Prple Black
075
Brown Brown Brown Brown Dark Grn Dark Grn Dark Grn Dark Grn
080
Brown Brown Brown Brown Dark Grn Dark Grn Dark Grn Dark Grn
090
Brown Brown Brown Brown Dark Grn Dark Grn Dark Grn Dark Grn
100
Brown Brown Brown Brown Dark Grn Dark Grn Dark Grn Dark Grn
110
Red Red Brown Brown Brown Brown Dark Grn Dark Grn Dk Prple Dk Prple Red Red
120
Red Red Brown Brown Brown Brown Gray Gray Dk Prple Dk Prple Red Red
130
Red Red Brown Brown Brown Brown Gray Gray Dk Prple Dk Prple Red Red
140
Red Red Brown Brown Brown Brown Dark Grn Dark Grn Dark Grn Dark Grn Dk Prple Dk Prple
150
Red Red Brown Brown Brown Brown Dark Grn Dark Grn Dark Grn Dark Grn Dk Prple Dk Prple
161
Red Red Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn
170
Red Red Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn
180
Red Red Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn
190
Red Red Brown Brown Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn Black Black
210
Red Red Brown Brown Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn Black Black
225
Red Red Brown Brown Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn Dark Grn Dark Grn
240
Red Red Brown Brown Brown Brown Brown Brown Gray Gray Dark Grn Dark Grn Dark Grn Dark Grn Dark Grn Dark Grn
