Si011359EA Compressor ASSY
Removal Procedure 13
2 Disconnect the
compressor lead wires.

Be careful so as not to burn
the compressor terminals or
the name plate.
Pattern 1
Pattern 2
S: yellow
C: blue
R: red
3 Remove the gasket.
4 Remove the 4 nuts of
the compressor.
Step Procedure Points
Yellow (S)
Blue (C)
Red (R)
(R5457)
(R20873)
S
R
C
(R20874)
S
C
R
Gasket
(R5458)
(R12888)
