Si011359EA Sound Blankets
Removal Procedure 11
4. Sound Blankets
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1
2
Remove the sound
blanket (top).
Remove the sound
blanket (body).

Since the piping ports on the
sound blanket are torn
easily, remove the sound
blanket carefully.
Sound blanket (body)
(R19300)
Sound blanket (top)
