Daikin BRC073A4 - Remote Controller Functions; Button Operation Details; LCD Display Behavior

User reference guide
8
BRC0731A4
3P422724-1
Names and Functions
1. Operation Mode Selector button
• Press this button to select the operation
mode of your preference. (See "Cool/
Heat/Fan/Dry/Auto Operation" on page 12)
• Available modes may vary with the
connected model.
2. Fan Speed/Airow Direction
button
• Used to change the fan speed and airow
direction. (See "Cool/Heat/Fan/Dry/Auto
Operation" on page 13)
• Available fan speeds and airow directions
may vary with the connected model.
3. Menu/Enter button
• This button is enabled by default.
To disable, refer to "Enable/disable the
Menu/Enter and Cancel button" on
page 11.
• Used to display the Main Menu or enter the
selected item (See "Main Menu Items
Overview" on page 19).
4. Up button
• Used to raise the set temperature.
• The next item on the upper side will be
highlighted.
(Keep pressing the button to cycle through
the values or items).
• Used to change the selected item.
5. Down button
• Used to lower the set temperature.
• The next item on the lower side will be
highlighted.
(Keep pressing the button to cycle through
the values or items).
• Used to change the selected item.
6. Right button
• Used to highlight the next items on the
right-hand side.
• The display contents are changed to the
next screen.
7. Left button
• Used to highlight the next items on the
left-hand side.
• The display contents are changed to the
previous screen.
8. ON/OFF button
• Press to start or stop the air conditioner.
9. Operation lamp (Green)
• This lamp lights up during operation.
• This lamp is not lit when the unit operation
is OFF.
• This lamp blinks if an error or mode conict
occurs.
10. Cancel button
• This button is enabled by default.
To disable, refer to "Enable/disable the
Menu/Enter and Cancel button" on
page 11.
• Used to return to the previous screen.
11. LCD (with backlight)
• The backlight will be lit for approximately
30 seconds when one of the buttons is
pressed.
• The actions linked to the buttons , except
for the ON/OFF button, are not carried out
when the backlight is not lit.
