• It may take some time unit the airflow
switch is completed, but this is normal.
• Fan speeds supported depend on the
model that is connected.
• In “ ” (Auto), the fan speed is
adjusted according to the set temperature
and the temperature in the room.
However, in FAN OPERATION mode, fan
speed is the same as that in “High”.
• The fan speed will not be displayed if the
indoor unit does not have fan speed
control function.
11
UP AND DOWN AIRFLOW
DIRECTION ADJUSTMENT
The up/dowm airflow direction position
switches each time the up/down airflow
direction button is pressed.
The air conditioner switches to automatic
airflow direction mode when the automatic
airflow direction button is pressed once.
When pressed again, the automatic airflow
direction mode is cancelled.
The left/right aitflow direction position
switches each time the left/right airflow
direction button is pressed.
P0
P0 P1 P2
P0
Swing
P4 P3
LEFT AND RIGHT AIRFLOW
DIRECTION ADJUSTMENT
P0
P0 P1 P2
Swing
P4 P3
AUTOMATIC SWITCHING OF
AIRFLOW DIRECTION
Movement of the airflow direction
blades.
Under the operating conditions described
below, airflow direction is controlled
automatically, so it may differ from the airflow
direction displayed on the remote controller.
Operating
conditions
When the room
temperature is
higher than the
set temperature
(for HEATING
OPERATION)
The air is blown
horizontally so
that the airflow
is not directed
at the body.
The air is blown
horizontally so
that the cold
airflow is not
directed at the
body.
When HEATING
OPERATION
starts and when
in DEFROST
OPERATION
mode (for
HEATING
OPERATION)
During
continuous
operation with
the air blowing
downward or
horizontally
The air conditioner
operates with a
different airflow
direction for a
certain period of
time to prevent
condensation
build-up on the
airflow direction
blades.
* HEATING OPERATION mode includes
cases in which operation is set to “ ”.
* Since it varies by model, refer to the
operation manual attached to indoor unit.
To Next Page
