SPECIFICATIONS
n Specifications
n Outline drawings
When using this unit an electric parts box of KJB311A is required.
For installation, a steel electric parts box to be embedded is mandatory.
Power supply 1 ~ 50/60Hz, 100V
–
240V
Power consumption Max. 8W
Forced ON/OFF input
Continuous “a” contact
Contact current: approximately 10mA
Size 180 (W) × 120 (H) × 64.5 (D)
Weight 420g
