Daikin DM96SE - Wiring Diagram and Airflow Data

35
A IRFLOW
1. CFM in chart is without filter(s). Filters do not ship with this furnace, but must be provided by the installer. If the furnace requires two return filters, this
chart assumes both filters are installed.
2. For most jobs, about 400 CFM per ton when cooling is desirable.
3. INSTALLATION and/or BLOWER SPEED CAN BE ADJUSTED TO OBTAIN TEMPERATURE RISE WITHIN THE RANGE SPECIFIED ON THE RATING PLATE.
4. The chart is for information only. For satisfactory operation, external static pressure must not exceed value shown on rating plate. The shaded area indicates
ranges in excess of maximum external static pressure allowed when heating. The data for 0.6" w.c. to 0.8" w.c. is shown for air conditioning purposes only.
5. At higher altitudes, a properly derated unit will have approximately the same temperature rise at a particular CFM, while the ESP at that CFM will be lower.
DM96SE*
Wire Color Function AC 0.1 Rise 0.2 Rise 0.3 Rise 0.4 Rise 0.5 Rise 0.6 0.7 0.8
Red High-Cool 3 1350 NA 1310 NA 1273 NA 1234 NA 1198 NA 1156 1117 1078
Blue Med Hi - Heat 2.5 1247 29 1212 30 1167 31 1129 32 1087 33 1043 997 952
Brown Med Low 2 1151 31 1107 32 1067 35 1021 35 977 36 928 880 835
Black Low 1.5 922 39 870 41 819 43 763 47 704 51 643 592 539
Orange Fan Only 1 779 46 661 54 588 NA 516 NA 455 NA 394 352 N/A
Red High-Cool 3 1364 NA 1332 NA 1285 NA 1246 NA 1206 NA 1170 1127 1083
Blue Med Hi - Heat 2.5 1259 42 1214 44 1175 45 1135 47 1091 49 1053 1008 957
Brown Med Low 2 1165 46 1121 48 1073 50 1033 52 984 54 929 876 832
Black Low 1.5 936 57 884 60 829 NA 770 NA 706 NA 645 593 539
Orange Fan only 1 815 NA 665 NA 596 NA 517 NA 451 NA 396 345 Na
Red High-Cool 5 2298 NA 2260 NA 2222 NA 2182 NA 2149 NA 2114 2087 2022
Blue Med Hi - Heat 4 1701 42 1641 43 1600 45 1548 46 1502 47 1454 1411 1366
Brown Med Low 3.5 1575 45 1528 47 1478 48 1426 50 1373 52 1323 1272 1220
Black Low 2.5 1302 55 57 60 1187 NA 1126 NA 1063 NA 1004 936 871
Orange Fan only 1.5 1056 NA 981 NA 915 NA 842 NA 764 NA 683 604 540
DM96SE0805CU
DM96SE0403BU
DM96SE0603BU
