Daikin DP 14 - Page 12

ACCESSORIES
12
MODEL A B
DHZ25FDPGCHMS 26 1/2 29 3/4
DHZ25FDPGCHMM 31 1/2 29 3/4
DHZ25FDPGCHML 30 29 3/4
MODEL A B
DHZ25MFDPGCHMS 26 1/2 29 3/4
DHZ25MFDPGCHMM 31 1/2 29 3/4
DHZ25MFDPGCHML 30 29 3/4
MANUAL
MOTORIZED
A
A
B
7 5/8
5 3/4
11 7/8
MOTORIZED/MANUAL FRESH AIR DAMPERS -
(HORIZONTAL APPLICATIONS)
MODEL A B C D E FILTER
DHZECNJPGCHM 25 1/4 18 1/8 18 13 3/4 16 1/8 16 x 25 x 1
DHZECNJPGCHL 35 1/4 18 1/8 18 18 1/4 16 1/8 16 x 25 x 1
ECONOMIZER
(HORIZONTAL APPLICATIONS)
Measurement in inches.
D
E
C
A
B
18
16 1/8
AB
31 1/2 29 3/4
30 29 3/4
AB
31 1/2 29 3/4
30 29 3/4DHZ25MFDPGCHML
MOTORIZED
MANUAL
DHZ25FDPGCHMM
DHZ25FDPGCHML
MODEL
MODEL
DHZ25MFDPGCHMM
