Daikin DP 14 - Page 13

13
ACCESSORIES
10
12 1/8
1
10
12 1/8
1
DDN25FDPG
C
DDN25FDP
G
SQUARE TO ROUND CONVERTER
(DOWNFLOW APPLICATIONS)
A
B
R
S
C
D
16
ø
16
ø
18
ø
18
ø
22 3/4 22 1/4
12 1/4 14 3/4
12 1/4 14 3/4
22 3/4 22 1/4
MODEL A B C D RETURN SUPPLY
SQRPG101/102 22 3/4 12 1/4 22 1/4 14 3/4 16 16
SQRPG103 22 3/4 12 1/4 22 1/4 14 3/4 18 18
MODEL A B
DDN25FDPGCHMM 16 16
DDN25FDPGCHML 18 16
MODEL A B
DDN25MFDPGCHMM 16 16
DDN25MFDPGCHML 18 16
MANUAL
MOTORIZED
MOTORIZED/MANUAL FRESH AIR DAMPERS
(DOWNFLOW APPLICATIONS)
10
12 1/8
6
1
10
12 1/8
6
1
5 3/4
5 3/4
BOTTOM VIEW
BOTTOM VIEW
DDN25FDPGCHML
DDN25FDPGCHMM
11 7/8
11 7/8
