6
NOTE: If removing only the coil access panel from the unit, the lter access panel must be removed rst. Failure to do so
may result in panel damage.
UPFLOW
Figure 3
DOWNFLOW
Figure 4
HORIZONTAL LEFT
Figure 5
HORIZONTAL RIGHT
Figure 6
Upper Tie Plate
Control
Deck
Downflow
Bracket
Center
Support
Filter
Bracket
Filter
Access
Panel
Blower
Access
Panel
Coil
Access
Panel
Tubing
Panel
UV
Knockout
INTERNAL PART TERMINOLOGY
Figure 7
EXTERNAL PART TERMINOLOGY
Figure 8
