11 | Configuration
Installer reference guide
188
ERLA11~16D + EBBH/X11+16D
Daikin Altherma 3 R W
4P643603-1B – 2022.05
3
Additional zone
Space heating/cooling
Main zone
Room
Tank
[3] Additional zone
Setpoint screen
[3.1] Schedule
[3.2] Heating schedule
[3.3] Cooling schedule
[3.4] Setpoint mode
[3.5] Heating WD curve
[3.6] Cooling WD curve
[3.7] Emitter type
[3.8] Setpoint range
[3.9] Control
[3.A] Ext thermostat type
[3.B] Delta T
[3.C] WD curve type
Setpoint screen
Control the leaving water temperature for the additional zone via setpoint screen
[3] Additional zone.
See "11.3.5Setpoint screen"[4156].
Schedule
Indicates if the desired leaving water temperature is according to a schedule.
See "11.6.3Main zone"[4177].
# Code Description
[3.1] N/A Schedule:
▪ No
▪ Yes
Heating schedule
Define a heating temperature schedule for the additional zone via [3.2] Heating
schedule.
See "11.4.3Schedule screen: Example"[4161].
Cooling schedule
Define a cooling temperature schedule for the additional zone via [3.3] Cooling
schedule.
See "11.4.3Schedule screen: Example"[4161].
Setpoint mode
The setpoint mode of the additional zone can be independently set from the
setpoint mode of the main zone.
See "Setpoint mode"[4179].
