11 | Configuration
Installer reference guide
218
ERLA11~16D + EBBH/X11+16D
Daikin Altherma 3 R W
4P643603-1B – 2022.05
# Code Description
[9.2.1] [E‑05]
(a)
[E‑06]
(a)
[E‑07]
(a)
▪ No DHW
No tank installed.
▪ EKHWS/E, small volume
Tank with booster heater installed at the side of
the tank, with a volume of 150l or 180l.
▪ EKHWS/E, big volume
Tank with booster heater installed at the side of
the tank, with a volume of 200l, 250l or 300l.
▪ EKHWP/HYC
Tank with optional booster heater installed at
the top of the tank.
▪ 3rd party, small coil
Third-party tank with a coil size larger than
1.05m².
▪ 3rd party, big coil
Third-party tank with a coil size larger than
1.80m².
(a)
Use the menu structure instead of the overview settings. Menu structure setting [9.2.1]
replaces the following 3 overview settings:
• [E-05]: Can the system prepare domestic hot water?
• [E-06]: Is a domestic hot water tank installed in the system?
• [E-07]: What kind of domestic hot water tank is installed?
In case of EKHWP, we recommend to use the following settings:
# Code Item EKHWP
[9.2.1] [E‑07] Tank type 5: EKHWP/HYC
N/A [4-05] Thermistor type 0: Automatic
[5.8] [6-0E] Maximum tank
temperature
≤70°C
In case of EKHWS*D* / EKHWSU*D*, we recommend to use the following settings:
# Code Item EKHWS*D* / EKHWSU*D*
150/180 200/250/300
[9.2.1] [E‑07] Tank type 0: EKHWS/E,
small volume
3: EKHWS/E, big
volume
N/A [4-05] Thermistor type 0: Automatic 1: Type 1
[5.8] [6-0E] Maximum tank
temperature
≤60°C ≤75°C
In case of a third-party tank, we recommend to use the following settings:
# Code Item Third-party tank
Coil≥1.05m² Coil≥1.8m²
[9.2.1] [E‑07] Tank type 7: 3rd party,
small coil
8: 3rd party,
big coil
N/A [4-05] Thermistor type 0: Automatic 1: Type 1
