Daikin F-Series User Manual

English
1-1
Original Instruction
OUTLINE AND DIMENSIONS
Indoor Unit: Ceiling Concealed Fan Coil Unit F Series
All dimensions are in mm
All dimensions are in mm
LEFT PIPING
RIGHT PIPING
KE
KD 31
32118348
31
KC
KB
140
KA32
20
552
129
20
11
143
87
71
247
186
31
KE
KD
KC
KB
KA
31
321183
48
31
140
32
552
11
186
87 71
31
247
20
20
129
143
Dimension
Model
KA KB KC KD KE
FWC02/03FD 619 477 437 440 501
FWC04/05FD 870 726 687 690 751
FWC06FD 1060 916 877 880 941
FWC08FD 1390 1246 1207 1210 1271
FWC10FD 1600 1456 1417 1420 1481
1 IM-CCFWD-0915(1)-DAIKIN-EN.ind1 11 IM-CCFWD-0915(1)-DAIKIN-EN.ind1 1 4/13/16 3:33:58 PM4/13/16 3:33:58 PM
