Table 8: Typical Parts List 60 Hz
Qty. Description Sym.
Part
Number
Qty. Description Sym.
Part
Number
1 Burner Wheel – 0.5" bore, CCW Burner Ignition Assembly
200-1000 MBH Furnace 034861102 1 200 - 1000 MBH Furnace 034742900
1100-1500 MBH Furnace 034249005 1 1100 - 2000 MBH Furnace 036518500
2000 MBH Furnace 034249004 1 Actuator— CSA Units VM1 034490101
1 Burner Motor – 0.25 HP, 115/60/1 1 Valve- Burner Pressure Regulator 034077600
200-1000 MBH Furnace 034249200 1 Valve- Manual: 200-320 MBH 034077300
1100-1500 MBH Furnace 032248600 1 Valve- Solenoid: 400- 1000 MBH 034488400
2000 MBH Furnace 032248400 1 Flame Safeguard FSG 073300803
Burner Gun Assembly: 1 Amplier 073300901
1 200 MBH Furnace 034879901 1 Flame Safeguard T.D. 90 Sec./UL Units 073301002
1 250 MBH Furnace 034879902 1 Flame Safeguard T.D. 30 Sec./CSA Units 073301001
1 320 MBH Furnace 034879903 1 Toggle Switch- 4PST S3 033536700
1 400 MBH Furnace 034879904 1 Ignition Transformer IT 034482600
1 500 MBH Furnace 034880001 1 Air Switch- Gas Burner AS 033003800
1 640 MBH Furnace 034880002 1 Fan Limit Control (until 9/08) FLC 073337102
1 650 MBH Furnace 034880002 1 Fan Limit Control (9/08 & later) FLC 193423703
1 790 MBH Furnace 034880003 1 Antunes Fan Limit Control 193423703
1 800 MBH Furnace 034880003 1
Ignition electrode, springs,
bushings, countersink
300032902
1 1000 MBH Furnace 034880004 1 Ignition electrode, springs, bushings 300032903
1 1100 MBH Furnace 035721001 Relays- No Controls Units (C12= YC, YM) — 1/01 & later
1 1400 MBH Furnace 035721002 1 Relay (before 1/10) R20 061019403
1 1500 MBH Furnace 035721003 1 Relay (before 1/10) R23 019643000
1 2000 MBH Furnace 036235700 1 Relay (after 3/10) R20A 349934764
Burner Blast Tube: 1 Relay (after 3/10) R23A 349934764
1 200 - 400 MBH Furnace 037378802 1 Relay (after 3/10) R20B 193454703
1 500 - 650 MBH Furnace 034101703 1 Relay (after 3/10) R23B 193454703
1 790 - 1000 MBH Furnace 034101707 1 Fan Motor Contactor (1100-2000 mbh only) M29 024700700
1 1100, 1400 MBH Furnace 034101706 Relays- MicroTech II Units (C12= _D or _S)
1 1500, 2000 MBH Furnace 035164701 1 Relay (before 1/10) R20 061019403
Burner Pilot Mixer 1 Relay (after 3/10) R20A 349934764
1 200-1000 MBH Furnace 036516401 1 Relay (after 3/10) R20B 193454703
1 1100-2000 MBH Furnace 036516402 1 Relay (before 3/10) R23 019643000
1 Burner Pilot Assembly 035019600 1 Relay (after 3/10) R23A 349934764
1 Relay (after 3/10) R23B 193454703
1 200 MBH Furnace 058599301 1 Fan Motor Contactor (1100-2000 mbh only) M29 024700700
1 250 MBH Furnace 058599302 Relays- MicroTech III units
1 320 MBH Furnace 058599303 1 Relay- High Amp DPDT/120V R20A 349934764
1 400 MBH Furnace 059861501 1 Relay- High Amp DPDT/120V R23A 349934764
1 500 MBH Furnace 058599101 1 Relay- Low Amp DPDT/120V R23B 193424341
1 640 MBH Furnace 058599102 1 Contactor- Burner Motor M29 349934764
1 650 MBH Furnace 058599103
1 790 MBH Furnace 058599104
1 800 MBH Furnace 058599104 For complete Gas Heat Parts List with Diagrams see the following:
1 1000 MBH Furnace 058599201 RPL 571177— RPS/RDT 015- 040 C Vintage
1 1100 MBH Furnace 059364601 RPL 7000069— RPS/RDT 045- 075 C Vintage
1 1400 MBH Furnace 059364602 RPL 7000070— RPS/RDT 080- 135 C Vintage
1 1500 MBH Furnace 059364603 RPL 7000150— RPS/RDT 015- 042 D Vintage
1 2000 MBH Furnace 059364604 RPL 7000137— RPS/RDT 045-079 D Vintage
RPL 7000108— RPS/RDT 080-140 D Vintage
IM 684-6 • ROOFTOP SYSTEMS 34 www.DaikinApplied.com
