Performance Data
Performance Tables
R410A Cooling Only
Model: FCRN18FXV1S - RN18CXV1S2
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
510
16°C
21°C
5.00 4.10 1.30 4.82 3.99 1.41 4.64 3.89 1.52 4.45 3.77 1.65 4.09 3.51 1.79 3.78 3.30 1.97
24°C
5.00 4.91 1.30 4.83 4.80 1.41 4.65 4.65 1.52 4.46 4.46 1.65 4.10 4.10 1.79 3.79 3.79 1.97
27°C
5.04 5.04 1.30 4.87 4.87 1.41 4.70 4.70 1.53 4.53 4.53 1.65 4.18 4.18 1.80 3.89 3.89 1.98
30°C
5.20 5.20 1.31 5.05 5.05 1.42 4.90 4.90 1.54 4.74 4.74 1.67 4.39 4.39 1.81 4.11 4.11 2.00
19°C
24°C
5.51 3.83 1.32 5.32 3.73 1.43 5.12 3.63 1.55 4.92 3.53 1.68 4.52 3.29 1.82 4.18 3.10 2.01
27°C
5.51 4.38 1.32 5.32 4.28 1.43 5.13 4.18 1.55 4.92 4.08 1.68 4.53 3.82 1.82 4.19 3.62 2.01
30°C
5.52 5.40 1.32 5.33 5.29 1.43 5.14 5.14 1.55 4.95 4.95 1.68 4.56 4.56 1.82 4.23 4.23 2.01
33°C
5.59 5.59 1.32 5.41 5.41 1.43 5.23 5.23 1.55 5.05 5.05 1.69 4.68 4.68 1.83 4.37 4.37 2.02
22°C
27°C
6.06 3.75 1.34 5.85 3.66 1.46 5.64 3.56 1.58 5.42 3.47 1.71 4.98 3.23 1.86 4.61 3.05 2.05
30°C
6.07 4.57 1.34 5.86 4.47 1.46 5.64 4.37 1.58 5.42 4.26 1.71 4.99 3.99 1.86 4.61 3.78 2.05
33°C
6.07 5.33 1.34 5.86 5.23 1.46 5.64 5.13 1.58 5.42 5.02 1.71 4.99 4.71 1.86 4.63 4.48 2.05
36°C
6.09 6.05 1.34 5.89 5.89 1.46 5.68 5.68 1.58 5.48 5.48 1.72 5.05 5.05 1.86 4.70 4.70 2.05
620
16°C
21°C
5.20 4.28 1.31 5.01 4.17 1.42 4.82 4.06 1.54 4.62 3.94 1.66 4.24 3.67 1.81 3.91 3.45 1.99
24°C
5.22 5.19 1.31 5.03 5.03 1.42 4.84 4.84 1.54 4.64 4.64 1.67 4.27 4.27 1.81 3.94 3.94 1.99
27°C
5.28 5.28 1.31 5.10 5.10 1.42 4.92 4.92 1.54 4.75 4.75 1.67 4.38 4.38 1.82 4.08 4.08 2.00
30°C
5.50 5.50 1.32 5.34 5.34 1.43 5.18 5.18 1.56 5.01 5.01 1.69 4.64 4.64 1.83 4.34 4.34 2.03
19°C
24°C
5.73 4.05 1.33 5.52 3.94 1.44 5.32 3.84 1.56 5.10 3.74 1.69 4.69 3.48 1.84 4.33 3.28 2.02
27°C
5.74 4.66 1.33 5.53 4.56 1.44 5.33 4.45 1.56 5.11 4.35 1.70 4.70 4.07 1.84 4.34 3.85 2.03
30°C
5.77 5.75 1.33 5.56 5.56 1.44 5.37 5.37 1.57 5.16 5.16 1.70 4.75 4.75 1.84 4.41 4.41 2.03
33°C
5.86 5.86 1.34 5.68 5.68 1.45 5.50 5.50 1.57 5.32 5.32 1.71 4.93 4.93 1.86 4.61 4.61 2.05
22°C
27°C
6.29 3.96 1.36 6.07 3.87 1.47 5.85 3.77 1.59 5.61 3.67 1.73 5.16 3.42 1.87 4.77 3.23 2.06
30°C
6.30 4.86 1.36 6.08 4.76 1.47 5.85 4.65 1.59 5.62 4.55 1.73 5.17 4.26 1.87 4.78 4.04 2.06
33°C
6.31 5.70 1.36 6.09 5.59 1.47 5.87 5.47 1.60 5.64 5.36 1.73 5.19 5.03 1.88 4.81 4.77 2.07
36°C
6.35 6.35 1.36 6.15 6.15 1.47 5.93 5.93 1.60 5.72 5.72 1.74 5.27 5.27 1.88 4.92 4.92 2.08
730
16°C
21°C
5.39 4.46 1.32 5.19 4.35 1.43 4.99 4.24 1.55 4.79 4.12 1.68 4.39 3.83 1.82 4.05 3.61 2.01
24°C
5.42 5.42 1.32 5.22 5.22 1.43 5.03 5.03 1.55 4.82 4.82 1.68 4.43 4.43 1.82 4.09 4.09 2.01
27°C
5.51 5.51 1.33 5.33 5.33 1.44 5.15 5.15 1.56 4.96 4.96 1.69 4.59 4.59 1.83 4.27 4.27 2.02
30°C
5.78 5.78 1.34 5.61 5.61 1.45 5.44 5.44 1.57 5.26 5.26 1.71 4.87 4.87 1.86 4.55 4.55 2.05
19°C
24°C
5.93 4.28 1.34 5.72 4.18 1.45 5.50 4.07 1.58 5.28 3.96 1.71 4.84 3.69 1.85 4.47 3.48 2.04
27°C
5.95 4.95 1.34 5.74 4.84 1.46 5.52 4.73 1.58 5.30 4.61 1.71 4.87 4.31 1.85 4.50 4.08 2.04
30°C
6.00 6.00 1.35 5.79 5.79 1.46 5.58 5.58 1.58 5.37 5.37 1.71 4.94 4.94 1.86 4.59 4.59 2.05
33°C
6.13 6.13 1.35 5.95 5.95 1.47 5.77 5.77 1.59 5.58 5.58 1.73 5.17 5.17 1.88 4.83 4.83 2.07
22°C
27°C
6.51 4.19 1.37 6.28 4.10 1.48 6.04 3.99 1.61 5.80 3.89 1.74 5.33 3.63 1.89 4.92 3.43 2.08
30°C
6.53 5.16 1.37 6.29 5.07 1.48 6.06 4.96 1.61 5.81 4.84 1.74 5.34 4.53 1.89 4.94 4.30 2.08
33°C
6.55 6.05 1.37 6.32 5.95 1.49 6.09 5.82 1.61 5.85 5.69 1.75 5.38 5.33 1.89 4.99 4.99 2.09
36°C
6.61 6.61 1.37 6.40 6.40 1.49 6.18 6.18 1.62 5.96 5.96 1.75 5.50 5.50 1.90 5.13 5.13 2.10
Remark:
AFR:Airowrate(CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB without pressure trip.
