41
Performance Data
Model: FFY20CXV1 - RY20CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
340
16°C
21°C 5.25 3.47 1.39 5.07 3.38 1.50 4.88 3.29 1.63 4.68 3.19 1.77 4.30 2.97 1.92 3.97 2.80 2.11
24°C 5.26 4.15 1.39 5.07 4.06 1.50 4.88 3.96 1.63 4.69 3.87 1.77 4.31 3.61 1.92 3.98 3.41 2.11
27°C 5.30 4.71 1.39 5.12 4.60 1.51 4.94 4.49 1.63 4.76 4.38 1.77 4.39 4.08 1.92 4.08 3.83 2.12
30°C 5.46 5.46 1.40 5.31 5.31 1.52 5.15 5.15 1.64 4.98 4.98 1.78 4.62 4.62 1.94 4.32 4.32 2.14
19°C
24°C 5.79 3.24 1.41 5.59 3.16 1.53 5.38 3.07 1.66 5.17 2.99 1.80 4.75 2.78 1.95 4.39 2.62 2.15
27°C 5.80 3.71 1.41 5.59 3.62 1.53 5.39 3.54 1.66 5.18 3.45 1.80 4.76 3.23 1.95 4.40 3.06 2.15
30°C 5.81 4.57 1.41 5.61 4.48 1.53 5.41 4.38 1.66 5.20 4.27 1.80 4.79 3.99 1.95 4.44 3.78 2.15
33°C 5.87 5.87 1.42 5.68 5.68 1.53 5.50 5.50 1.66 5.31 5.31 1.81 4.91 4.91 1.96 4.59 4.59 2.17
22°C
27°C 6.37 3.17 1.44 6.15 3.09 1.56 5.93 3.02 1.69 5.70 2.93 1.83 5.24 2.73 1.99 4.85 2.58 2.19
30°C 6.38 3.86 1.44 6.15 3.78 1.56 5.93 3.70 1.69 5.70 3.61 1.83 5.24 3.38 1.99 4.85 3.20 2.19
33°C 6.38 4.51 1.44 6.16 4.43 1.56 5.93 4.34 1.69 5.70 4.25 1.83 5.25 3.99 1.99 4.86 3.79 2.19
36°C 6.40 5.12 1.44 6.19 5.01 1.56 5.97 4.91 1.69 5.76 4.80 1.84 5.31 4.50 1.99 4.94 4.27 2.20
410
16°C
21°C 5.46 3.62 1.40 5.27 3.53 1.52 5.07 3.43 1.64 4.86 3.33 1.78 4.46 3.10 1.93 4.11 2.92 2.13
24°C 5.48 4.39 1.40 5.28 4.29 1.52 5.09 4.19 1.64 4.88 4.08 1.78 4.48 3.81 1.93 4.15 3.59 2.13
27°C 5.55 4.99 1.41 5.36 4.87 1.52 5.18 4.75 1.65 4.99 4.61 1.79 4.61 4.28 1.94 4.29 4.00 2.14
30°C 5.78 5.78 1.42 5.61 5.61 1.53 5.44 5.44 1.66 5.26 5.26 1.81 4.88 4.88 1.96 4.56 4.56 2.17
19°C
24°C 6.02 3.42 1.43 5.81 3.34 1.54 5.59 3.25 1.67 5.36 3.16 1.81 4.93 2.95 1.97 4.55 2.78 2.17
27°C 6.03 3.94 1.43 5.82 3.86 1.54 5.60 3.77 1.67 5.37 3.68 1.81 4.94 3.44 1.97 4.56 3.26 2.17
30°C 6.06 4.86 1.43 5.85 4.76 1.55 5.64 4.65 1.68 5.42 4.54 1.82 4.99 4.24 1.97 4.63 4.01 2.17
33°C 6.16 6.16 1.43 5.97 5.97 1.55 5.78 5.78 1.68 5.59 5.59 1.83 5.18 5.18 1.99 4.84 4.84 2.19
22°C
27°C 6.61 3.35 1.45 6.38 3.27 1.57 6.14 3.19 1.71 5.90 3.10 1.85 5.42 2.89 2.01 5.02 2.73 2.21
30°C 6.62 4.11 1.45 6.39 4.03 1.57 6.15 3.94 1.71 5.91 3.85 1.85 5.43 3.60 2.01 5.02 3.42 2.21
33°C 6.63 4.82 1.45 6.40 4.73 1.57 6.17 4.63 1.71 5.93 4.53 1.85 5.45 4.25 2.01 5.05 4.04 2.21
36°C 6.68 5.45 1.46 6.46 5.34 1.58 6.23 5.23 1.71 6.01 5.11 1.86 5.54 4.78 2.02 5.17 4.51 2.22
450
16°C
21°C 5.67 3.78 1.41 5.46 3.68 1.53 5.25 3.58 1.66 5.03 3.48 1.80 4.62 3.24 1.95 4.25 3.05 2.15
24°C 5.70 4.59 1.42 5.49 4.48 1.53 5.28 4.37 1.66 5.07 4.25 1.80 4.66 3.97 1.95 4.30 3.74 2.15
27°C 5.79 5.26 1.42 5.60 5.12 1.54 5.41 4.98 1.67 5.22 4.82 1.81 4.82 4.47 1.96 4.49 4.17 2.17
30°C 6.08 6.08 1.43 5.90 5.90 1.55 5.72 5.72 1.68 5.53 5.53 1.83 5.12 5.12 1.99 4.78 4.78 2.19
19°C
24°C 6.24 3.62 1.44 6.01 3.53 1.56 5.78 3.44 1.69 5.55 3.35 1.83 5.09 3.12 1.98 4.70 2.94 2.18
27°C 6.26 4.19 1.44 6.03 4.09 1.56 5.80 4.00 1.69 5.57 3.90 1.83 5.11 3.65 1.98 4.73 3.45 2.19
30°C 6.31 5.16 1.44 6.08 5.04 1.56 5.87 4.93 1.69 5.64 4.80 1.83 5.19 4.49 1.99 4.82 4.23 2.19
33°C 6.44 6.44 1.45 6.26 6.26 1.57 6.06 6.06 1.70 5.86 5.86 1.85 5.43 5.43 2.01 5.08 5.08 2.22
22°C
27°C 6.84 3.54 1.46 6.60 3.46 1.59 6.35 3.38 1.72 6.10 3.29 1.86 5.60 3.07 2.02 5.18 2.90 2.23
30°C 6.86 4.37 1.47 6.61 4.28 1.59 6.37 4.19 1.72 6.11 4.10 1.87 5.61 3.84 2.02 5.19 3.64 2.23
33°C 6.88 5.12 1.47 6.64 5.03 1.59 6.40 4.92 1.72 6.15 4.81 1.87 5.66 4.51 2.03 5.24 4.28 2.23
36°C 6.94 5.78 1.47 6.73 5.67 1.59 6.49 5.55 1.73 6.26 5.41 1.88 5.78 5.05 2.04 5.40 4.75 2.25
Model: FFY20CXV1 - RY20CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.458 3.458 3.914 3.914 4.066 4.066 5.737 5.737 6.649 6.649 7.105 7.105 7.560 7.560
17°C 3.367 3.367 3.538 3.538 3.974 3.974 5.730 5.730 6.554 6.554 7.009 7.009 7.464 7.464
19°C 3.277 3.277 3.162 3.162 3.883 3.883 5.723 5.723 6.459 6.459 6.914 6.914 7.368 7.368
21°C 3.186 3.186 3.030 3.030 3.791 3.791 5.642 5.642 6.364 6.364 6.818 6.818 7.272 7.272
23°C 3.095 3.095 3.142 3.142 3.700 3.700 5.486 5.486 6.269 6.269 6.723 6.723 7.176 7.176
25°C 3.005 3.005 3.254 3.254 3.608 3.608 5.331 5.331 6.174 6.174 6.627 6.627 7.080 7.080
27°C 2.914 2.914 3.366 3.366 3.517 3.517 5.175 5.175 6.080 6.080 6.532 6.532 6.984 6.984
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
