Performance Data
Model: FHYC20EXV1 - RY20CXV1
Cooling Mode
AFR
(CFM)
EWB EDB
Outdoor temperature
19°C 25°C 30°C 35°C 40°C 46°C
TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI TC SC PI
430
16°C
21°C 5.39 4.01 1.49 5.20 3.91 1.61 5.01 3.80 1.74 4.81 3.69 1.89 4.41 3.44 2.05 4.08 3.23 2.26
24°C 5.40 4.80 1.49 5.21 4.69 1.61 5.02 4.58 1.74 4.81 4.47 1.89 4.42 4.17 2.05 4.09 3.94 2.26
27°C 5.44 5.44 1.49 5.26 5.26 1.61 5.08 5.08 1.75 4.89 4.89 1.90 4.51 4.51 2.06 4.19 4.19 2.27
30°C 5.61 5.61 1.50 5.45 5.45 1.62 5.28 5.28 1.76 5.11 5.11 1.91 4.74 4.74 2.08 4.43 4.43 2.29
19°C
24°C 5.95 3.74 1.51 5.74 3.65 1.64 5.53 3.55 1.77 5.31 3.45 1.92 4.88 3.22 2.09 4.51 3.03 2.30
27°C 5.95 4.28 1.51 5.74 4.19 1.64 5.53 4.09 1.77 5.31 3.99 1.92 4.88 3.73 2.09 4.52 3.54 2.30
30°C 5.96 5.29 1.51 5.76 5.17 1.64 5.55 5.06 1.78 5.34 4.94 1.93 4.92 4.62 2.09 4.56 4.37 2.31
33°C 6.03 6.03 1.52 5.84 5.84 1.64 5.65 5.65 1.78 5.45 5.45 1.93 5.05 5.05 2.10 4.72 4.72 2.32
22°C
27°C 6.54 3.67 1.54 6.32 3.58 1.67 6.09 3.49 1.81 5.85 3.39 1.96 5.38 3.16 2.13 4.98 2.98 2.34
30°C 6.55 4.47 1.54 6.32 4.37 1.67 6.09 4.27 1.81 5.85 4.17 1.96 5.38 3.90 2.13 4.98 3.70 2.35
33°C 6.55 5.22 1.54 6.32 5.12 1.67 6.09 5.02 1.81 5.85 4.91 1.96 5.39 4.61 2.13 4.99 4.38 2.35
36°C 6.57 5.92 1.54 6.35 5.80 1.67 6.13 5.68 1.81 5.91 5.55 1.97 5.45 5.20 2.13 5.07 4.94 2.35
530
16°C
21°C 5.61 4.18 1.50 5.41 4.08 1.63 5.20 3.97 1.76 4.99 3.86 1.91 4.58 3.59 2.07 4.23 3.38 2.28
24°C 5.63 5.08 1.50 5.43 4.96 1.63 5.22 4.84 1.76 5.01 4.72 1.91 4.60 4.40 2.07 4.26 4.16 2.28
27°C 5.70 5.70 1.51 5.50 5.50 1.63 5.32 5.32 1.77 5.12 5.12 1.92 4.73 4.73 2.08 4.41 4.41 2.30
30°C 5.93 5.93 1.52 5.76 5.76 1.64 5.59 5.59 1.78 5.40 5.40 1.94 5.01 5.01 2.10 4.68 4.68 2.32
19°C
24°C 6.18 3.96 1.53 5.96 3.86 1.65 5.74 3.76 1.79 5.51 3.65 1.94 5.06 3.41 2.11 4.67 3.21 2.32
27°C 6.19 4.56 1.53 5.97 4.46 1.65 5.75 4.36 1.79 5.52 4.25 1.94 5.07 3.98 2.11 4.69 3.77 2.32
30°C 6.22 5.62 1.53 6.01 5.50 1.66 5.79 5.38 1.79 5.57 5.25 1.95 5.13 4.91 2.11 4.76 4.64 2.33
33°C 6.33 6.33 1.53 6.13 6.13 1.66 5.94 5.94 1.80 5.74 5.74 1.96 5.32 5.32 2.13 4.97 4.97 2.35
22°C
27°C 6.79 3.88 1.56 6.55 3.78 1.68 6.31 3.69 1.83 6.06 3.59 1.98 5.57 3.35 2.15 5.15 3.16 2.37
30°C 6.80 4.76 1.56 6.56 4.66 1.69 6.32 4.55 1.83 6.07 4.45 1.98 5.58 4.16 2.15 5.16 3.95 2.37
33°C 6.81 5.57 1.56 6.58 5.47 1.69 6.34 5.35 1.83 6.09 5.24 1.98 5.60 4.92 2.15 5.19 4.67 2.37
36°C 6.86 6.30 1.56 6.63 6.18 1.69 6.40 6.05 1.83 6.17 5.91 1.99 5.69 5.53 2.16 5.31 5.22 2.38
600
16°C
21°C 5.82 4.37 1.51 5.61 4.25 1.64 5.39 4.14 1.77 5.17 4.03 1.92 4.74 3.75 2.09 4.37 3.53 2.30
24°C 5.85 5.30 1.52 5.64 5.18 1.64 5.43 5.05 1.78 5.21 4.92 1.93 4.78 4.59 2.09 4.42 4.33 2.30
27°C 5.94 5.94 1.52 5.75 5.75 1.65 5.56 5.56 1.78 5.36 5.36 1.94 4.95 4.95 2.10 4.61 4.61 2.32
30°C 6.24 6.24 1.53 6.06 6.06 1.66 5.87 5.87 1.80 5.68 5.68 1.96 5.26 5.26 2.13 4.91 4.91 2.35
19°C
24°C 6.41 4.19 1.54 6.17 4.08 1.67 5.94 3.98 1.81 5.70 3.87 1.96 5.23 3.61 2.12 4.83 3.40 2.34
27°C 6.42 4.84 1.54 6.19 4.73 1.67 5.96 4.62 1.81 5.72 4.51 1.96 5.25 4.22 2.13 4.85 3.99 2.34
30°C 6.48 5.96 1.54 6.25 5.83 1.67 6.02 5.70 1.81 5.79 5.56 1.96 5.33 5.19 2.13 4.95 4.89 2.35
33°C 6.62 6.62 1.55 6.42 6.42 1.68 6.23 6.23 1.82 6.02 6.02 1.98 5.58 5.58 2.15 5.22 5.22 2.38
22°C
27°C 7.03 4.10 1.57 6.78 4.01 1.70 6.52 3.91 1.84 6.26 3.80 2.00 5.75 3.55 2.17 5.32 3.35 2.38
30°C 7.04 5.05 1.57 6.79 4.95 1.70 6.54 4.85 1.84 6.27 4.74 2.00 5.76 4.44 2.17 5.33 4.20 2.39
33°C 7.07 5.92 1.57 6.82 5.82 1.70 6.57 5.69 1.85 6.31 5.57 2.00 5.81 5.22 2.17 5.38 4.95 2.39
36°C 7.13 6.68 1.57 6.91 6.56 1.71 6.67 6.42 1.85 6.43 6.26 2.01 5.94 5.84 2.18 5.54 5.50 2.41
Model: FHYC20EXV1 - RY20CXV1
Heating Mode
ID DB
Outdoor WB
-9°C -6°C -5°C 6°C 12°C 15°C 18°C
TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)
15°C 3.458 3.458 3.914 3.914 4.066 4.066 5.737 5.737 6.649 6.649 7.105 7.105 7.560 7.560
17°C 3.367 3.367 3.424 3.424 3.971 3.971 5.730 5.730 6.538 6.538 6.991 6.991 7.444 7.444
19°C 3.277 3.277 2.934 2.934 3.877 3.877 5.723 5.723 6.428 6.428 6.878 6.878 7.328 7.328
21°C 3.186 3.186 2.784 2.784 3.782 3.782 5.633 5.633 6.317 6.317 6.764 6.764 7.212 7.212
23°C 3.095 3.095 2.973 2.973 3.688 3.688 5.458 5.458 6.207 6.207 6.651 6.651 7.095 7.095
25°C 3.005 3.005 3.163 3.163 3.593 3.593 5.283 5.283 6.096 6.096 6.538 6.538 6.979 6.979
27°C 2.914 2.914 3.353 3.353 3.499 3.499 5.108 5.108 5.985 5.985 6.424 6.424 6.863 6.863
Frost Region
Remark:
AFR: Air fl ow rate (CFM)
EWB: Entering Wet Bulb Temp. (°C)
EDB: Entering Dry Bulb Temp. (°C)
TC: Total Cooling / Heating Capacity (kW)
SC: Sensible Cooling / Heating Capacity (kW)
PI: Power Input (kW)
Notes:
1. Ratings shown are net capacities.
2. shows nominal capacities.
3. Direct interpolation is permissible. Do not extrapolate.
4. Unit is able to operate at ambient from 19°C to 46°C DB (cooling) / -9°C to 18°C WB (heating) without pressure trip.
