FT09/13DV2S, FT25/35DVM, FT25/35DSG Si01-501
154 Removal Procedure
Step Procedure Points
2. Removing the horizontal
blade (small)
1
2
3
Remove the horizontal
blade (small) while
bending the fixed part
at the center slightly.
Unfasten the left side.
Unfasten the key type
fixing shaft at the right
side.
(R4859)
