Si01-501 FT09/13DV2S, FT25/35DVM, FT25/35DSG
Removal Procedure 161
3
4
Remove the electrical
box by sliding it to the
left.
Disconnect the wire
harness.
5. Removing the signal
receiver PCB
1
Remove the signal
receiver PCB by
opening the hooks at 3
positions.
2
Disconnect the
connector from the
signal receiver PCB.
Step Procedure Points
(R4362)
