Daikin FT35DVM - Page 173

FT09/13DV2S, FT25/35DVM, FT25/35DSG Si01-501
164 Removal Procedure

In case of FT35DSG,
FT13DV2S.
[S1] To DC fan motor
[S6] To swing motor
[S21] HA connector
[S26] To display PCB
[S28] To signal receiver PCB
[S32] To heat exchanger
thermistor
Step Procedure Points
[S1]
Fuse
(holder type
w/cap)
[S6]
[S26][S28]
[S32]
[S21]
(R4866)
Varistor (w/cap)
