FT09/13DV2S, FT25/35DVM, FT25/35DSG Si01-501
176 Removal Procedure
3. Removing the bearing
1
Remove the screw of
the drip proof plate
(left).
2
The drip proof plate can
be removed when the
hooks at 2 positions are
unfastened.
3
Press the rubber-made
bearing with force from
outside.
4
Remove the bearing.
Step Procedure Points
