Si01-501 FT15DV2S, FT50/60DSG
Removal Procedure 191
2. Removing the indoor unit.
1
Detach the indoor unit
from the installation
plate.
3. Removing the piping
fixture.
1
Release the claw on the
upper side of the piping
fixture on the back of
the unit.
4. Removing the heat
exchanger.
1
Widen the auxiliary
piping to the extent of
10°~20°.

At an angle of 10°~20°
Step
Procedure Points
