Daikin FTE25LV1 - Front Grille; Remove the front grille

Si041265EC Front Grille
Removal Procedure 3
2. Front Grille
Warning

Be sure to wait for 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1 Remove the 2 screws.
2 Unfasten the 2 hooks
on the top.
3 Remove the front grille.

When reassembling, make
sure that all hooks are
securely fastened.
(R18500)
Front
grille
Hook
(R2519)
(R2521)

In case that the hooks can
not be pressed from above,
remove the front grille while
pushing the hook from the
space between the front
grille and the indoor heat
exchanger.
