Check SiBE121123_A
209 Service Diagnosis
8.5 Power Supply Waveforms Check
Check No.11 Measure the power supply waveform between No. 1 and No. 2 on the terminal board, and check
the waveform disturbance.
Check to see if the power supply waveform is a sine wave (Fig.1).
Check to see if there is waveform disturbance near the zero cross (sections circled in Fig.2)
Fig.1 Fig.2
(R1736)
(R1444)
To Next Page
