Specifications 24
Floor / Ceiling Suspended Dual Type
50 Hz, 220 - 230 - 240 V
Model
FLXS25BAVMB FLXS35BAVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Front Panel Color Almond White Almond White
Airflow Rates
H
m³/min
(cfm)
7.6 (268) 9.2 (325) 8.6 (304) 9.8 (346)
M 6.8 (240) 8.3 (293) 7.6 (268) 8.9 (314)
L 6.0 (212) 7.4 (261) 6.6 (233) 8.0 (282)
SL 5.2 (184) 6.6 (233) 5.6 (198) 7.2 (254)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 34 34
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.33 - 0.32 - 0.31 0.36 - 0.34 - 0.33 0.38 - 0.36 - 0.35 0.38 - 0.36 - 0.35
Power Consumption (Rated) W 70 - 70 - 70 74 - 74 - 74 78 - 78 - 78 78 - 78 - 78
Power Factor (Rated) % 96.4 - 95.1 - 94.1 93.4 - 94.6 - 93.4 93.3 - 94.2 - 92.9 93.3 - 94.2 - 92.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 490 × 1,050 × 200 490 × 1,050 × 200
Packaged Dimensions (H × W × D) mm 280× 1,100 × 566 280 × 1,100 × 566
Weight (Mass) kg 16 16
Gross Weight (Gross Mass) kg 22 22
Sound
Pressure
Level
H / M / L / SL dB(A) 37 / 34 / 31 / 28 37 / 34 / 31 / 29 38 / 35 / 32 / 29 39 / 36 / 33 / 30
Sound Power Level dB 51 51 53 54
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D081090 3D081091
Model
FLXS50BAVMB
Cooling Heating
Rated Capacity 5.0 kW Class
Front Panel Color Almond White
Airflow Rates
H
m³/min
(cfm)
11.4 (403) 12.1 (427)
M 10.0 (353) 9.8 (346)
L 8.5 (300) 7.5 (265)
SL 7.5 (265) 6.8 (240)
Fan
Type Sirocco Fan
Motor Output W 34
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.48 - 0.45 - 0.43 0.47 - 0.45 - 0.44
Power Consumption (Rated) W 96 - 96 - 96 96 - 96 - 96
Power Factor (Rated) % 90.9 - 92.8 - 93.0 92.8 - 92.8 - 90.9
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 490 × 1,050 × 200
Packaged Dimensions (H × W × D) mm 280 × 1,100 × 566
Weight (Mass) kg 17
Gross Weight (Gross Mass) kg 24
Sound
Pressure
Level
H / M / L / SL dB(A) 47 / 43 / 39 / 36 46 / 41 / 35 / 33
Sound Power Level dB 60 59
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Drawing No. 3D081092
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
