Si041144 Removal of Horizontal Blades / Swing Motors
Removal Procedure 19
5. Removal of Horizontal Blades / Swing Motors
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power
supplies before disassembling work.
Step Procedure Points
1. Remove the horizontal
blades.
1
Hold the indoor unit up
with a piece of wood
etc.
(R16287)
Horizontal blade
(R16515)
left
(R16516)
inner right
