READ BEFORE OPERATION READ BEFORE OPERATION
Open the front panel
Streamer air inlet
•
Air inlet for streamer operation.
Streamer unit
Prevents mold and allergens
with the decomposition power
of the streamer discharge.
Outdoor Unit
For RKF25*35/50/60*, ARKF25*35
* Appearance of outdoor units may differ from some model
Outside air temperature sensor: (Back)
• It senses the ambient temperature around the unit.
Air outlet
Earth terminal:
• It is inside of this cover.
Drain hose
Air inlet:
(Back and side)
Refrigerant piping and
inter-unit cable
Names of Parts
6
