SiENBE12-713 Outdoor Unit
Removal Procedure 311
3
Undo the fixing strings,
open the sound blanket
(body) and pull it out.
4
Open the sound blanket
(inner) and pull it out.
Step
Procedure Points
Sound blanket
(inner)
