Specifications SiENBE12-713
14 Specifications
1. Specifications
1.1 Indoor Units - Cooling Only
Wall Mounted Type 50Hz 230V
Model FTKS20D3VMW FTKS20D3VML
Rated Capacity 2.0kW Class 2.0kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 8.7 (307) 8.7 (307)
M 6.7 (237) 6.7 (237)
L 4.7 (166) 4.7 (166)
SL 3.9 (138) 3.9 (138)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.16 0.16
Power Consumption (Rated) W 35 35
Power Factor % 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 38/25/22 38/25/22
Sound Power H dBA 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ18.0 φ18.0
Drawing No. 3D051079 3D051080
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model FTKS25D3VMW FTKS25D3VML
Rated Capacity 2.5kW Class 2.5kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 8.7 (307) 8.7 (307)
M 6.7 (237) 6.7 (237)
L 4.7 (166) 4.7 (166)
SL 3.9 (138) 3.9 (138)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.16 0.16
Power Consumption (Rated) W 35 35
Power Factor % 95.1 95.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 38/25/22 38/25/22
Sound Power H dBA 56 56
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ18.0 φ18.0
Drawing No. 3D051081 3D051082

Daikin FTKS50FV1B Specifications

General

Cooling Capacity	5.0 kW
Energy Efficiency Ratio (EER)	3.21
Energy Efficiency Ratio (Cooling)	3.21
Type	Split Air Conditioner
Refrigerant	R410A
Power Supply	220-240V / 50Hz
